The DryAir Mixing/Booster Pump is a versatile component designed for enhancing fluid temperature control and flow in heating systems. Here are its key specifications and features:
Specifications:
- Model: MB100
- Electrical Requirements: 115V, single phase, 15A
- For cord lengths exceeding 75 ft (23m), a 12-gauge supply cord is recommended.
- Pump Type: Goulds, 1 hp (0.75 kW)
- Dimensions: 50″ L x 18″ W x 20″ H
- Weight: 105 lbs (48 kg)
Features:
- Low Temperature Control: Automatically maintains lower fluid temperatures suitable for applications like concrete curing.
- Dual Temperature Control: Capable of providing high and low temperature fluids simultaneously, allowing for different heating needs (e.g., high temperature for structure heating and lower temperature for curing).
- Pressure and Flow Boost: Enhances flow rates and can extend pumping distances by up to 300 feet from the central heating module.
Monitoring and Controls:
- Equipped with an Aquastat for temperature setting, supply and return temperature gauges, a pump control switch, and a modulating/mixing valve.
This pump is particularly useful in setups requiring flexible temperature management and increased pumping capacity.
