| Burner |
Two stage, Diesel fuel / #1 or #2 heating oil, 85% efficient |
| Input Capacity |
896,000 BTU/H (260 KW/H) |
| Output Capacity |
761,600 BTU/H (221 KW/H) |
| Fuel Consumption |
6.4 US GPH (24.2 LPH, 20.7 KG/H) |
| Weight |
Dry: 2,800 LB (1,270 KG) • Wet: 4,100 LB (1,860 KG) |
| Electrical |
Single phase, 115/230 V, 60 Hz, 30 Amps |
| Loading – Standard |
Forklift pockets on all sides |
| Heat Exchanger |
Water jacket / fire tube type |
| Fluid Volume |
45 US Gal (170 L) |
| Fluid Temperature Range |
120°F to 200°F (49°C to 93°C) |
| Fuel Tank |
Welded steel |
| Fuel Capacity |
187 US Gal (708 L) |
| Operating Range (Full Output) |
29 hours |
| Climate Control System |
Maintains optimum burner reliability and efficiency across all ambient conditions. Assures reliable start-up and operation in any temperature. |
| Before Start-up – Pre-heater |
4000 Watt electric circulation heater, 230 V; preheats heat exchanger glycol before system start-up |
| During Operation – Fuel Heater |
Automatically maintains set fuel temperature via hot glycol-to-fuel heat transfer |
| During Operation – Combustion Air Heater |
Automatically maintains set combustion air temperature via hot glycol-to-air heat transfer coil |
| Control & Monitoring |
Pump and temperature controls with full gauge panel showing circulation fluid temperatures & pressures, fuel pressures, and 8-light system operation feature for easy troubleshooting |
| Internal Fluid Circulation System |
Atmospherically vented, low pressure, single supply & return; adjustable fluid temperature control; auto pressure bypass for pump protection and variable flow demands; auto temperature bypass for heat exchanger protection |
| Circulation Pump |
2900 RPM • 2 HP (1.5 KW) • 80 US GPM @ 30 PSI (16 M³/HR @ 21 M W.C.) |
| Primary Circulation |
2” (50 mm) fluid circulation lines, 2” (50 mm) ball valves, and 2” (50 mm) Kamlock quick couplers |
| Heat Transfer Fluid (HTF) |
Non-toxic propylene glycol / water mixture, freeze protected |
| Lock-Out Package |
Locks out primary “supply” and “return” fluid circulation valves and control panel |
